Solar LED Street Light

Kingsun LED solar street light RL1A series, representative of solar LED street lamp series, could be completely fed with wind and solar power without grid-connection. Combined with advantages of wind and solar power, energy generated by wind turbine and solar panel is charged into batteries and transferred to electricity by inverters. Having an experienced team stand by, we could customize the ideal solution of LED solar lights system based on every single client.
<a href='http://www.kslights.com/products/solar-led-street-lights/' target='_blank'><u>Solar LED Street Light</u></a>

Kingsun Solar LED Street Light

SN	Solar & Wind LED Street Lighting System	Product Code/Specs.	Description	Quality
1	LED Street Light head for solar-wind hybrid.	24V	108*1W LEDs, aluminium alloy housing,IP66	1
2	Miniature wind driven power generator	KS-A400L 24V	Complete with turbine,rotor blade and vertical fin	1
3	Controller	KS24400	For charging control,protection to battery and turbine.Working with solar energy(≤150W)	1
4	Solar Panel and Holder	120W 12V	120W/12V Monocrystalline silicon/polycrystalline silicon	2
5	Storage Battery	200AH 12V	200H 12V,Value Regulated Lead Acid Battery	2

Luminaire Technical Parameters
Luminaire Code	KS-A108T4
Input Voltage	DC 20-29V
Max Input Current	2A
The max power consumption of the 2 control lines	DC 3MA+3MA
LED Comsumption	108W
LED Luminous Efficiency	>90Lm/W
LED Initial Flux LED	>9720Lm
Lamp's Efficiency	90%
Average Illumination@6M height	>42LUX
Average Illumination@8M height	>23.6LUX
Average Illumination@10M height	>15LUX
Effective Illumination Area@6M height	7.2x21M²
Effective Illumination Area@8M height	9.6x28M²
Effective Illumination Area@10M height	12x35M²
Color Temperature	4000~5500K
Color Rendering Index (CRI)	Ra>75
Light Distribution Curve/Beam Pattern	Bat Wing/Rectangular Beam
Junction Temperature (Tj)	<75℃
Working Enviornment	-40℃~50℃
IP Rating	IP66
Working Life	>50000 hours
Light Body & Lampshade Material	Aluminum Alloy
